1968-1974 AMC Javelin 2-Row Aluminum Radiator, 16" Fan & Shroud Combo – Cools Up to 600 HP
Upgrade your cooling system with this high-performance 2-row aluminum radiator and 16-inch electric fan shroud combo designed specifically for 1968-1974 AMC Javelin models. Featuring a 1-inch core and efficient aluminum construction, this radiator is capable of cooling engines producing up to 600 horsepower, making it ideal for street performance, muscle cars, and restoration projects.
The radiator includes a fully mounted 16-inch electric fan, aluminum shroud, 13 lb. radiator cap, and an integrated transmission cooler for automatic transmission applications. The complete assembly is engineered to deliver maximum airflow and reliable cooling performance in demanding driving conditions.
Radiator Specifications:
- Overall Dimensions: 22" tall x 27.25" wide (23.13" wide with fill neck)
- Core Dimensions: 15.88" tall x 24.13" wide x 1.58" thick
- Inlet: 1.5" Passenger Side
- Outlet: 1.5" Driver Side
- Tank Thickness: 2.5"
- Tube Thickness: 0.75"
- Total Assembly Thickness: 6" to fan motor
- Verify clearance before installation
Included Components:
- 2-Row Aluminum Radiator
- 16" Electric Cooling Fan (Bracket Mounted)
- Aluminum Fan Shroud
- 13 lb. Radiator Cap
- Built-In Transmission Cooler (1/2"-20 Straight Thread, Inverted Flare)
Available Cooling Fan Upgrades:
- SPAL High Performance Series 2049 Fan – 2,024 CFM, 19 Amp Draw
Optional Add-Ons:
- Waterproof Thermostat Relay Kit (185°F On / 170°F Off)
- Polished Aluminum Overflow Tank with Twist-In Cap
Whether you're restoring a classic AMC Javelin or building a high-horsepower street machine, this aluminum radiator, fan, and shroud package delivers dependable cooling performance, improved airflow, and a clean, professional appearance under the hood.
