1932 Ford 2-Row Radiator - Pass Outlet

Radiator Dimensions:

Radiator Dimensions:
Total: 20" wide (lower bracket) x 26.5" tall
Core: 17" wide x 20" tall x 1.75" thick
Inlet: 1.5" driver side
Outlet: 1.75" passenger side
Tanks: 3" thick | 17.5" wide
Tubes: 0.75" thick

Whats Included

Bracket Mounted
13lb. Radiator Cap included
Transmission Cooler Included (1/8-27NPT)

SPAL High Performance Series -2049
16" Cooling Fan
Curved Blade - Pull

Specifications:
A: Length 16.30"
B: Depth 3.47"
C: Width 15.75"

CFM: 2024
AMP Draw: 19 Amp

Thermostat / Relay Kit:

Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°

POLISHED OVERFLOW TANK:

Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets

48" Polished Stainless Steel Radiator Hose Kit:

4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
