1949-1954 Chevy Bel Air LS Swap 3-Row Radiator, Shroud, Fan Combo
Total thickness: 6.5" to fan motor
3-Row Core | Cools up to 650hp
**Note: For LS Swaps
3- ROW 1949-1954 Chevy Bel Air LS RADIATOR 16" Fan & SHROUD COMBO
3-Row Core | Cools up to 650hp
Radiator Dimensions:
Total: 23.63" tall (Incl Cap) x 25.25" wide (Including Brackets)
Core: 17.13" tall x 21.75" wide x 2.5" thick
Inlet: 1.25" passenger side
Outlet: 1.5" passenger side
Tanks: 3" thick
Tubes: 0.63" thick
*Verify clearance for electric fan
Total thickness: 6.5" to fan motor
Whats Included
16" Fan with 1600 cfm
Bracket Mounted
13lb. Radiator Cap included
Aluminum shroud
* Added Steam port for LS engines
Add On Options
Fan Upgrades:
SPAL High Performance Series -2049
16" Cooling Fan
Curved Blade - Pull
Specifications:
A: Length 16.30"
B: Depth 3.47"
C: Width 15.75"
CFM: 2024
AMP Draw: 19 Amp
SPAL MediumProfile Series -1516
16" Cooling Fan
Straight Blade - Pull
Specifications:
A: Length 16.3"
B: Depth 2.48"
C: Width 15.75"
CFM: 1604
AMP Draw: 13 Amps
Thermostat / Relay Kit:
Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°
POLISHED OVERFLOW TANK:
Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
48" Polished Stainless Steel Radiator Hose Kit:
4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
| Engine | Chevy LS |
|---|
