1955-1959 Chevy Truck LS Swap 3-Row Black Radiator, Shroud, Fan Combo
Steam port added for LS motors
1955-1959 Chevy Truck LS Swap 3-Row Black Radiator, Shroud, Fan Combo
3-Row Core | 700hp Rating
Radiator Dimensions:
Total: 26.75" tall (with cap) x 26.5" wide (including brackets)
Core: 19.38" tall x 21.75" wide x 2" thick
Inlet: 1.25" Passenger side
Outlet: 1.5" Passenger side
Tanks 2.5" thick
Tubes: 0.63" thick
Total Thickness: 7.25" to fan motor
Whats Included
16" Fan (1600cfm)
Bracket Mounted
13lb. Radiator Cap included
Transmission Cooler Included (1/2"-20 Straight Thread, Inverted Flare)
Aluminum shroud
Steam port added for ls motors
Add On Options
Fan Upgrades:
SPAL High Performance Series -2049
16" Cooling Fan
Curved Blade - Pull
Specifications:
A: Length 16.30"
B: Depth 3.47"
C: Width 15.75"
CFM: 2024
AMP Draw: 19 Amp
Thermostat / Relay Kit:
Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°
POLISHED OVERFLOW TANK:
Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
48" Polished Stainless Steel Radiator Hose Kit:
4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
| Engine | Chevy LS |
|---|
