1959-1963 Impala LS Swap 3-Row Radiator, Shroud, Fan Combo
*Added Steam port for LS Motors
DOES NOT WORK WITH GMC 605 STEERING BOX
3- ROW 1959-1963 Impala Radiator 16" Fan & SHROUD COMBO
3-Row Core | Cools up to 650hp
Radiator Dimensions:
Total: 21.25" tall (21.75" with cap) x 28" (with brackets) (27" Center)
Core: 16" tall x 24.5" wide x 2.5" thick
Inlet: 1.25" passenger side
Outlet: 1.5" passenger side
Tanks: 2.75" thick
Tubes: 0.75" thick
*Added Steam port for LS Motors
Whats Included
16" Fan (1900 cfm)
Bracket Mounted
13lb. Radiator Cap included
Transmission Cooler Included (1/2"-20 Straight Thread, Inverted Flare)
Aluminum shroud
Add On Options
Fan Upgrades:
SPAL High Performance Series -2049
16" Cooling Fan
Curved Blade - Pull
Specifications:
A: Length 16.30"
B: Depth 3.65"
C: Width 15.75"
CFM: 2467
AMP Draw: 26 Amps
Thermostat / Relay Kit:
Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°
POLISHED OVERFLOW TANK:
Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
48" Polished Stainless Steel Radiator Hose Kit:
4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
| Engine | Chevy LS |
|---|
