1961-1965 Lincoln Continental LS Swap 3-Row Dual Pass Radiator, Shroud, Dual Fan Combo
- Steam port added for LS Motors
1961-1965 Lincoln Continental 3- ROW Dual Pass Radiator, 13" Fans & SHROUD COMBO
3-Row Core | Cools 700hp
Radiator Dimensions:
CORE DIM (H x W): 17 1/4 X 25 3/4
OVERALL (H x W): 20 1/8 X 30 1/8
HOSE LOCATIONS: IN: PASSENGER - OUT: PASSENGER
HOSE FITTINGS: IN: 16ORB(FEMALE) - OUT: 16ORB(FEMALE)
MOUNTING TYPE: OEM
FLOW DIRECTION: CROSS FLOW
CORE ROWS: 3
CORE THICKNESS: 2 1/4
Tank Width: 2.5
Total thickness with Radiator, Shroud, and Fans : 7.50" thick
Whats Included
- 13" Fans - 1100 CFM Each
- Bracket Mounted
- 13lb. Radiator Cap included
- Transmission Cooler included (1/4-18NPT)
- Aluminum shroud
- Steam port added for LS Motors
Add On Options
Thermostat / Relay Kit:
Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°
POLISHED OVERFLOW TANK:
Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
48" Polished Stainless Steel Radiator Hose Kit:
4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
| Engine | Chevy LS |
|---|
