1963-1966 Chevy C10 Truck LS Swap 3-Row Radiator
3-Row Core | Cools up to 600hp
Steam port added for LS Motors
1963-1966 Chevy C10 Truck 3- ROW Radiator
3-Row Core | Cools up to 600hp
Upgrade the cooling system of your 1963-1966 Chevy C10 Truck with our premium 3-Row Radiator. Engineered for optimal performance and durability, our radiator is designed to keep your classic Chevy C10 running smoothly and efficiently. Enhance your driving experience with reliable cooling solutions tailored for your vintage truck.
Radiator Dimensions:
Total: 22.5" tall (23.5" with cap) x 25.25" wide
Core: 17.38" tall x 22.75" wide x 1.75" thick
Inlet: 1.25" passenger side
Outlet: 1.5" passenger side
Tanks: 2.75" thick (top); 2.38" thick (bottom)
Tubes: 0.75" thick
Whats Included
Saddle Mounted
13lb. Radiator Cap included
Transmission Cooler Included (1/2"-20 Straight Thread, Inverted Flare)
Steam port added for LS Motors
Add On Options
Fan Upgrades:
SPAL High Performance Series -2049
16" Cooling Fan
Curved Blade - Pull
Specifications:
A: Length 16.30"
B: Depth 3.47"
C: Width 15.75"
CFM: 2024
AMP Draw: 19 Amp
Thermostat / Relay Kit:
Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°
POLISHED OVERFLOW TANK:
Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
48" Polished Stainless Steel Radiator Hose Kit:
4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
| Engine | Chevy LS |
|---|
