1965 - 1967 Plymouth Satellite 3-Row Black Radiator, Shroud, Fan Combo
3-Row Core | Cools up to 550hp
1963 - 1967 Plymouth Fury 3- ROW radiator, 16" Fan & SHROUD COMBO
3-Row Core | Cools up to 550hp
Radiator Dimensions:
Total: 21.63" tall (22.87" with cap) x 26" wide (with brackets)
Core: 17.13" tall x 22" wide x 1.75" thick
Inlet: 1.5" Driver side off-center
Outlet: 1.5" Driver side
Tanks: 3.5" thick
Tubes: 0.75" thick
Total Thickness: 6.25"
Whats Included
16" Fan
Bracket Mounted
13lb. Radiator Cap included
Transmission Cooler Included (1/8-27NPT)
Aluminum shroud
Add On Options
Fan Upgrades:
SPAL High Performance Series -2049
16" Cooling Fan
Curved Blade - Pull
Specifications:
A: Length 16.30"
B: Depth 3.47"
C: Width 15.75"
CFM: 2024
AMP Draw: 19 Amp
Thermostat / Relay Kit:
Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°
POLISHED OVERFLOW TANK:
Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
48" Polished Stainless Steel Radiator Hose Kit:
4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
