1973-1987 Chevy C10 Truck LS Swap 3-Row Radiator, Shroud, Dual Fan Combo
1973-1987 Chevy C10 Truck 3- ROW 14" Fans & SHROUD COMBO
3 Row Core | Cools 1000hp
Dual Pass / LS Conversions
Radiator Dimensions:
Total: 20.63" tall (21.25" with cap) x 33.25" wide
Core: 19" tall x 28.25" wide x 2.5" thick
Inlet: (Choice your size below) passenger side
Outlet: (Choice your size below) passenger side
Tanks: 2.75" thick
Tubes: 0.63" thick
Whats Included
- 14" Fans
- Saddle Mounted
- 16lb. Billet Radiator Cap included
- Steam Port with 1/4" barbed fitting and plug included
- Aluminum shroud
ALL Aluminum Core Dual-Pass Features
Add On Options
Fan Upgrades:
SPAL High Performance Series -2044
13" Cooling Fan
Curved Blade - Pull
Specifications:
A: Length 14.17"
B: Depth 3.45"
C: Width 13.62"
CFM: 1777
AMP Draw: 19.5 Amps
Thermostat / Relay Kit:
Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°
POLISHED OVERFLOW TANK:
Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
48" Polished Stainless Steel Radiator Hose Kit:
4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
16AN Hose Kit
Complete your install with a clean look braided an hose line and swivel ends.
| Engine | Chevy LS |
|---|
