1996-2004 GMC Sonoma 3-Row Radiator, Shroud, Dual Fan Combo

$534.98

In stock

SKU

CC1826-1826FS12SP-gmc

Verify clearance for electric fan
3-Row Core | Cools up to 600hp

New Design is complete with Internal Engine Oil Cooler
If you remove the lower pins this radiator is only 16.25" tall
Does not fit 4 Cyl

Add Ons

Upgrade to SPAL-2029 High Performance 12" fans (3.5" thick, 500 More CFM) + $100.00

Thermostat/ Relay Kit + $69.98

2" x 13" Polished Overflow Tank + $39.98

48" Polished Stainless Steel Hose kit (4 end caps to make 2 hoses) + $69.98

Polished Billet Aluminum Radiator Cap + $19.98

Polishing Options

Radiator Polishing + $70.00

Fan Shroud Polishing + $50.00

Qty

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Upgrade your 1996-2004 GMC Sonoma with our 3-Row Aluminum Radiator, Shroud & Dual Fan Combo. Designed for maximum cooling efficiency, this direct-fit setup keeps your engine running at optimal temperatures, even under high-performance or heavy-duty conditions. Featuring lightweight aluminum construction, triple-core design, and powerful dual electric fans, this radiator combo is the perfect solution for street, towing, or off-road applications.

1996-2004 GMC Sonoma 3-Row Radiator, Shroud, Dual Fan Combo

3-Row Core | Cools up to 600hp

Radiator Dimensions:

Total: 16.25"(18" incl pins) tall x 32" wide
Core: 14.75" tall x 26.25" wide x 2" thick

Inlet: 1.38" driver side
Outlet: 1.5" passenger side
Tanks: 2.63" thick
Tubes: 0.63" thick
Total Thickness: 5.75" (4.75" between fan motors)

Whats Included

- 12" Fans
- Pin Mounted
- 13lb. Radiator Cap included
- Transmission Cooler Included (1/2"-20 Straight Thread, Inverted Flare)
- Engine Oil Cooler Included (Metric 20-1.5)
- Aluminum shroud

1996-2004 GMC Sonoma Radiator shroud fan

Add On Options

Fan Upgrades:

SPAL High Performance Series -2029
12" Cooling Fan
Curved Blade - Pull

Specifications:
A: Length 13.03"
B: Depth 3.45"
C: Width 12.64"

CFM: 1451
AMP Draw: 14.5 Amps

1451 CFM fan

Thermostat / Relay Kit:

Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°

POLISHED OVERFLOW TANK:

Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets

48" Polished Stainless Steel Radiator Hose Kit:

4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)
