2011-2016 Chevy Silverado 2500/ 3500 Radiator
2011-2016 Chevy Silverado 2500/ 3500 6.6l Diesel Radiator
2 Row Plastic Tank Aluminum Core
Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation
Built to OE Specifications to Ensure:
High Performance
Durability
Drop-In Fit
Whats Included
- OEM specified Plastic Tank-Aluminum Core Construction
- Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
- Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
Tubes - Welded Type or Latest Generation "B-Tube" Design
- Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
- 100% leak tested before leaving factory at 150% of operating pressure
- Industry Best Packaging - "10 Foot Drop Test" Standard
- Drop-in Fit
- High Performance Transmission Cooler with special Built-in Turburlator, when applicable
- All components are installed, torqued, & tested on Radiator during assembly
Applications:
2011-2016 Chevrolet Silverado 2500 HD 6.6L V8
2011-2016 Chevrolet Silverado 3500 HD 6.6L V8
2011-2016 GMC Sierra 2500 HD 6.6L V8
2011-2016 GMC Sierra 3500 HD 6.6L V8
| Bottom Hose Fitting (in): | 2 Right | Box Height (in): | 7 7/16 |
|---|---|---|---|
| Box Length (in): | 45 13/16 | Box Weight (lbs): | 29 |
| Box Width (in): | 31 5/8 |
Core Length (in): | 33 7/16 |
| Core Material: | Aluminum | Core Thickness (in): | 2 1/16 |
| Core Width (in): | 27 1/2 | Cross-flow/ Down-flow: | Cross Flow |
| Hazardous Material: | No | Inlet Length (in): | 28 1/8 |
| Inlet Width (in): | 2 7/16 | No. Of Rows: | 2 |
| Oil Cooler (in): | 11 1/2 (high-efficiency Plate Type) |
Outlet Length (in): | 28 1/8 |
| Outlet Width (in): | 2 7/16 |
Radiator Cap Supplied: | No |
| Tank Material: | Plastic | Tech Note: | O.E.M. style Plastic tanks & Aluminum core;with quick-connect outlet pipe & quick-connect oil cooler fittings. |
| Top Hose Fitting (in): | 1 13/16 Left |
| Reference Number | Reference Name |
|---|---|
| 13244 | DPI |
| 23172440 | OEM |
| 25838892 | OEM |
| 8013244 | APDI |
| CU13244 | SPI |
| GM3010576 | Partslink |
