Universal Viking Coilover Kit
This is a kit option to simplify ordering just the coilovers separate from one of my full kit packages that includes mounting brackets. You would do this if you already have mounts situated and just need the shocks and springs.
This includes:
2x Viking “Warrior” double adjustable shocks
2x Viking 2.5″ coilover springs
1x Viking thrust washer spanner wrench kit
How to Measure Ride Height:
This diagram indicates how Viking measures the ride height of an installed shock / strut. To get your ride height, make sure the vehicle is sitting level on the ground, and take the measurement as shown below. When measuring a stud mount, measure to the first washer that you come to as you move up or down the shock body (before the bushing). When measuring a t-bar or bearing mount, measure from the center of the mount.
Specs:
| Part Number | Ride Height | Compress Height | Extended Height | Shock Stroke | Spring Length |
|---|---|---|---|---|---|
| C201 | 9 5/8 - 10 1/4" | 8.53" | 11.33" | 2.80" | 7" |
| C202 | 9 5/8 - 10 1/4" | 8.53" | 11.33" | 2.80" | 7" |
| C203 | 10 3/4 - 11 1/2" | 9.31" | 12.91" | 3.60" | 8" |
| C204 | 10 3/4 - 11 1/2" | 9.31" | 12.91" | 3.60" | 8" |
| C205 | 11 5/8 - 12 1/2" | 9.94" | 14.14" | 4.20" | 9" |
| C206 | 11 5/8 - 12 1/2" | 9.94" | 14.14" | 4.20" | 9" |
| C217 | 12 1/4 - 13 1/4" | 10.38" | 15.03" | 4.65" | 10" |
| C218 | 12 1/4 - 13 1/4" | 10.38" | 15.03" | 4.65" | 10" |
| C207 | 13 1/8 - 14 1/4" | 11.00" | 16.25" | 5.25" | 10" |
| C208 | 13 1/8 - 14 1/4" | 11.00" | 16.25" | 5.25" | 10" |
| C209 | 13 3/4 - 15" | 11.47" | 17.22" | 5.75" | 12" |
| C210 | 13 3/4 - 15" | 11.47" | 17.22" | 5.75" | 12" |
| C211 | 15 1/8 - 16 1/2" | 12.47" | 19.22" | 6.75" | 14" |
| C212 | 15 1/8 - 16 1/2" | 12.47" | 19.22" | 6.75" | 14" |
| C213 | 15 1/2 - 17" | 12.75" | 19.75" | 7.00" | 14" |
| C214 | 15 1/2 - 17" | 12.75" | 19.75" | 7.00" | 14" |
| C219 | 16 5/8 - 18 1/4" | 13.50" | 21.25" | 7.75" | 14" |
| C220 | 16 5/8 - 18 1/4" | 13.50" | 21.25" | 7.75" | 14" |
| C215 | 18 3/8 - 20 1/4" | 14.75" | 23.75" | 9.00" | 14" |
| C216 | 18 3/8 - 20 1/4" | 14.75" | 23.75" | 9.00" | 14" |
| C201-Stud Top | 9 1/8 - 9 3/4" | 8.00" | 10.80" | 2.80" | 7" |
| C203-Stud Top | 10 1/4 - 11" | 8.78" | 12.38" | 3.60" | 8" |
| C205-Stud Top | 11 1/8 - 12" | 9.41" | 13.61" | 4.20" | 9" |
| C217-Stud Top | 11 3/4 - 12 3/4" | 9.85" | 14.50" | 4.65" | 10" |
| C207-Stud Top | 12 1/2 - 13 5/8" | 10.47" | 15.72" | 5.25" | 10" |
| C209-Stud Top | 13 1/4 - 14 1/2" | 10.94" | 16.69" | 5.75" | 12" |
| C211-Stud Top | 14 5/8 - 16" | 11.94" | 18.69" | 6.75" | 14" |
| C213-Stud Top | 15 - 16 1/2" | 12.22" | 19.22" | 7.00" | 14" |
| C219-Stud Top | 16 - 17 5/8" | 12.97" | 20.72" | 7.75" | 14" |
| C215-Stud Top | 17 3/4 - 19 5/8" | 14.22" | 23.22" | 9.00" | 14" |
